| Part Number | M240HW01 V8 |
| Mark | AUO |
| Gréisst | 24.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | M240HW01 V8 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 24.0 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 531.36×298.89 mm |
| skizzéieren | 556×323.2×14.9 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 3.5/1.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampe Typ | 14S4PWLEDWithout Driver |
| Signal Interface | LVDS (4 ch, 8-bit), 66 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| M240HTD01.0 | AUO | 24.0 | 1920×1080 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| M240HTN01.2 | AUO | 24.0 | 1920×1080 |
| M240HVN02.0 | AUO | 24.0 | 1920×1080 |
| M240HW01 V1 | AUO | 24.0 | 1920×1080 |
| M240HW01 V8 | AUO | 24.0 | 1920×1080 |
| M240HW01 VB | AUO | 24.0 | 1920×1080 |
| M240HW01 VC | AUO | 24.0 | 1920×1080 |
| M240HW02 V5 | AUO | 24.0 | 1920×1080 |
| M240HW02 V7 | AUO | 24.0 | 1920×1080 |
| CLAA150XP01 | CPT | 15.0 | 1024×768 |
| LK235D3HA0S | SHARP | 23.6 | 1920×1080 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M170EN01 V9 | AUO | 17.0 | 1280×1024 |
| M201UN02 V6 | AUO | 20.1 | 1600×1200 |
| M215XTN01.0 | AUO | 21.5 | 1366×768 |
| MT170EN01 V.1 | Innolux | 17.0 | 1280×1024 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
