AUO M240HW01 VC Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


M240HW01 VC

M240HW01 VC
M240HW01 VC
M240HW01 VC
M240HW01 VC thumb M240HW01 VC thumb M240HW01 VC thumb
Mark
AUO
Gréisst
24.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
200
CR
600:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
13804
Spezifikatioune

Part Number M240HW01 VC
MarkAUO
Gréisst24.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet200
CR600:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkAUO
Panel ModellM240HW01 VC
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst24.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich531.36×298.89 mm
skizzéieren556×323.2×12 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet200 cd/m² (Typ.)
Kontrast Verhältnis600:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC)
Äntwert Zäit3.5/1.5 (Typ.)(Tr/Td)
Vue Wénkel45/45/20/40 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ2 pcsCCFLWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
