M240HW02 V5

M240HW02 V5
M240HW02 V5
M240HW02 V5 thumb M240HW02 V5 thumb
Mark
AUO
Gréisst
24.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
350
CR
5000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
12769
Spezifikatioune

Part Number M240HW02 V5
MarkAUO
Gréisst24.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet350
CR5000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellM240HW02 V5
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst24.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusVA, Normally Black, Transmissive
aktiv Beräich531.36×298.89 mm
skizzéieren556×323.2 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet350 cd/m² (Typ.)
Kontrast Verhältnis5000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit7/5 (Typ.)(Tr/Td)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz120Hz
Lampe Typ20S4P×2CNWLEDWithout Driver
Signal InterfaceLVDS (4 ch, 8-bit), 66 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
M240HTN01.1 AUO 24.0 1920×1080
M240HVN01.0 AUO 24.0 1920×1080
M240HVN02.0 AUO 24.0 1920×1080
M240HW01 V0 AUO 24.0 1920×1080
M240HW01 V1 AUO 24.0 1920×1080
M240HW01 V2 AUO 24.0 1920×1080
M240HW01 VB AUO 24.0 1920×1080
M240HW01 VC AUO 24.0 1920×1080
M240HW02 V6 AUO 24.0 1920×1080
M240HW02 V7 AUO 24.0 1920×1080
Hot Produit
HM215WU3-100 BOE 21.5 1920×1080
LM185WH1-TLF4 LG Display 18.5 1366×768
LM215WF2-SLD1 LG Display 21.5 1920×1080
LM215WF3-SLD1 LG Display 21.5 1920×1080
LM270WQ1-SDA2 LG Display 27.0 2560×1440
LTM185AT05 Samsung 18.5 1366×768
LTM220CS01 Samsung 22.0 1920×1200
M270H1-L01 Innolux 27.0 1920×1080
MT220WW01 V.6 Innolux 22.0 1680×1050
NA19020-C961 Fujitsu 19.0 1280×1024
