AUO M240HVN02.0 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


M240HVN02.0

M240HVN02.0
M240HVN02.0
M240HVN02.0
M240HVN02.0 thumb M240HVN02.0 thumb M240HVN02.0 thumb
Mark
AUO
Gréisst
24.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
250
CR
3000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
305
Spezifikatioune

Part Number M240HVN02.0
MarkAUO
Gréisst24.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet250
CR3000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellM240HVN02.0
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst24.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusVA, Normally Black, Transmissive
aktiv Beräich531.36×298.89 mm
skizzéieren544.8×318.6×10 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet250 cd/m² (Typ.)
Kontrast Verhältnis3000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit7/5 (Typ.)(Tr/Td)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ15S4PWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
M240HTD01.0 AUO 24.0 1920×1080
M240HTN01.1 AUO 24.0 1920×1080
M240HVN01.0 AUO 24.0 1920×1080
M240HVN02.0 AUO 24.0 1920×1080
M240HW01 V0 AUO 24.0 1920×1080
M240HW01 V1 AUO 24.0 1920×1080
M240HW01 V2 AUO 24.0 1920×1080
M240HW01 V8 AUO 24.0 1920×1080
M240HW02 V1 AUO 24.0 1920×1080
M240HW02 V7 AUO 24.0 1920×1080
