M240HW01 V1

M240HW01 V1
M240HW01 V1
M240HW01 V1 thumb M240HW01 V1 thumb
Mark
AUO
Gréisst
24.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
250
CR
1000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
14477
Spezifikatioune

Part Number M240HW01 V1
MarkAUO
Gréisst24.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet250
CR1000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellM240HW01 V1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst24.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich531.36×298.89 mm
skizzéieren556×323.2×15.05 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet250 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit3.4/1.6 (Typ.)(Tr/Td); 2 (Typ.)(G to G)
Vue Wénkel85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
M240HTD01.0 AUO 24.0 1920×1080
M240HTN01.2 AUO 24.0 1920×1080
M240HVN01.0 AUO 24.0 1920×1080
M240HVN02.0 AUO 24.0 1920×1080
M240HW01 V0 AUO 24.0 1920×1080
M240HW01 V2 AUO 24.0 1920×1080
M240HW01 VB AUO 24.0 1920×1080
M240HW02 V1 AUO 24.0 1920×1080
M240HW02 V5 AUO 24.0 1920×1080
M240HW02 V6 AUO 24.0 1920×1080
