| Part Number | HT15X23-100 |
| Mark | HYDIS |
| Gréisst | 15.0 |
| Applikatioun | DMPC |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 450:1 |
| Faarwen | 16.2M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | BOE HYDIS |
| Panel Modell | HT15X23-100 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | AFFS, Normally Black, Transmissive |
| aktiv Beräich | 304.128×228.096 mm |
| skizzéieren | 331.6×254.7 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 450:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC), CIE193165% |
| Äntwert Zäit | 40 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | DMPC |
