LM270WF3-TLA1

LM270WF3-TLA1
LM270WF3-TLA1
LM270WF3-TLA1 thumb LM270WF3-TLA1 thumb
Mark
LG Display
Gréisst
27.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
400
CR
1000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
13639
Spezifikatioune

Part Number LM270WF3-TLA1
MarkLG Display
Gréisst27.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet400
CR1000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkLG Display
Panel ModellLM270WF3-TLA1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst27.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich597.888×336.312 mm
skizzéieren630×368.2 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet400 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit1/4 (Typ.)(Tr/Td); 3 (Typ.)(G to G)
Vue Wénkel85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
Frequenz120Hz
Lampe TypWLEDWithout Driver
Signal InterfaceLVDS (4 ch, 8-bit), 92 pins
Input Volt12.0V (Typ.)
ApplikatiounDMPC
