| Part Number | M215HW01 V0 |
| Mark | AUO |
| Gréisst | 21.5 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | M215HW01 V0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 21.5 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 476.64×268.11 mm |
| skizzéieren | 495.6×292.2×16.85 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 3.8/1.2 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| M215H3-LA1 | Innolux | 21.5 | 1920×1080 |
| M215HGE-L10 | Innolux | 21.5 | 1920×1080 |
| M215HGJ-P02 | Innolux | 21.5 | 1920×1080 |
| M215HJK-L3B | Innolux | 21.5 | 1920×1080 |
| M215HNE-L30 | Innolux | 21.5 | 1920×1080 |
| M215HW01 V0 | AUO | 21.5 | 1920×1080 |
| M215HW01 V7 | AUO | 21.5 | 1920×1080 |
| M215HW01 VB | AUO | 21.5 | 1920×1080 |
| M215HW03 V1 | AUO | 21.5 | 1920×1080 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| A260J2-001 | Innolux | 25.5 | 1920×1200 |
| LM190E08-TLGD | LG Display | 19.0 | 1280×1024 |
| LM201WE2-SLA1 | LG Display | 20.1 | 1680×1050 |
| LM201WE4-TLB2 | LG Display | 20.1 | 1680×1050 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LTM215HT05 | Samsung | 21.5 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| TM150XG-22L01A | SANYO | 15.0 | 1024×768 |
| TX41D96VC1FAA | KOE | 16.1 | 1400×1050 |
