M215HJK-L3B

M215HJK-L3B
M215HJK-L3B
M215HJK-L3B
M215HJK-L3B thumb M215HJK-L3B thumb M215HJK-L3B thumb
Mark
Innolux
Gréisst
21.5
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
250
CR
3000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
860
Spezifikatioune

Part Number M215HJK-L3B
MarkInnolux
Gréisst21.5
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet250
CR3000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkINNOLUX
Panel ModellM215HJK-L3B
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst21.5 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusMVA, Normally Black, Transmissive
aktiv Beräich476.064×267.768 mm
skizzéieren499.48×291.24 mm
UewerflächHard coating (6H)
Hellegkeet250 cd/m² (Typ.)
Kontrast Verhältnis3000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit20/5 (Typ.)(Tr/Td)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
M215H3-LA1 Innolux 21.5 1920×1080
M215HGE-L10 Innolux 21.5 1920×1080
M215HGE-L21 Innolux 21.5 1920×1080
M215HGJ-P02 Innolux 21.5 1920×1080
M215HGK-L30 Innolux 21.5 1920×1080
M215HJJ-L30 Rev.B1 Innolux 21.5 1920×1080
M215HNE-L30 Innolux 21.5 1920×1080
M215HW01 V0 AUO 21.5 1920×1080
M215HW01 VB AUO 21.5 1920×1080
M215HW03 V1 AUO 21.5 1920×1080
