Innolux M215H1-L03 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


M215H1-L03

M215H1-L03
M215H1-L03
M215H1-L03
M215H1-L03 thumb M215H1-L03 thumb M215H1-L03 thumb
Mark
Innolux
Gréisst
21.5
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
300
CR
1000:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
9665
Spezifikatioune

Part Number M215H1-L03
MarkInnolux
Gréisst21.5
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet300
CR1000:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkCMO
Panel ModellM215H1-L03
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst21.5 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich476.64×268.11 mm
skizzéieren495.6×292.2×16.85 mm
UewerflächAntiglare (Haze 25%), Hard coating (3H)
Hellegkeet300 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit1.3/3.7 (Typ.)(Tr/Td)
Vue Wénkel85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ4 pcsCCFLWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
