| Part Number | M215XTN01.0 |
| Mark | AUO |
| Gréisst | 21.5 |
| Applikatioun | DMPC |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | M215XTN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 21.5 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 476.64×267.96 mm |
| skizzéieren | 495.6×292.2 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 3.8/1.2 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 10S4PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| CLAA215FA04 V4 | CPT | 21.5 | 1920×1080 |
| HR215WU1-100 | BOE | 21.5 | 1920×1080 |
| LC215DTCA | PANDA | 21.5 | 1920×1080 |
| LC215EUN-SCA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| M215H1-L02 | Innolux | 21.5 | 1920×1080 |
| M215HTN01.0 | AUO | 21.5 | 1920×1080 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| M215XTN01.0 | AUO | 21.5 | 1366×768 |
| ITQX20H | IDTech | 20.8 | 2048×1536 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LM171WX3-TLC2 | LG Display | 17.1 | 1440×900 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LM190E0A-SLA1 | LG Display | 19.0 | 1280×1024 |
| LM230WU3-STC3 | LG Display | 23.0 | 1920×1200 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M185XTN01.3 | AUO | 18.5 | 1366×768 |
| M190CGE-L20 | Innolux | 19.0 | 1440×900 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
