| Part Number | LSUGC202XA |
| Mark | ALPS |
| Gréisst | 8.9 |
| Applikatioun | |
| Opléisung | 640×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 160 |
| CR | 3:1 |
| Faarwen | Monochrome |
| Géigeliicht | CCFL |
| Interface | Parallel Data |
| Panel Mark | ALPS |
| Panel Modell | LSUGC202XA |
| Panel Typ | STN-LCD , LCM |
| Panel Gréisst | 8.9 inch |
| Resolutioun | 640×240 , HVGA |
| Display Modus | STN, Blue mode |
| aktiv Beräich | 211.18×79.18 mm |
| skizzéieren | 270.2×112.2 mm |
| Uewerfläch | |
| Hellegkeet | 160 cd/m² (Typ.) |
| Kontrast Verhältnis | 3 : 1 (Typ.) |
| weisen Faarwen | Monochrome |
| Äntwert Zäit | 250/120 (Typ.)(Tr/Td) |
| Vue Wénkel | 30/30/15/30 (Min.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel Data (4-bit), 12 pins |
