| Part Number | TD043MTEA1 |
| Mark | TPO |
| Gréisst | 4.3 |
| Applikatioun | |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 400:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | TPO |
| Panel Modell | TD043MTEA1 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 4.3 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | Normally Black, Transmissive |
| aktiv Beräich | 93.6×56.16 mm |
| skizzéieren | 100.6×68.45 mm |
| Uewerfläch | |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 60 pins |
| Input Volt | 3.3/5.0/-5V (Typ.)(VCC/VDDP/VDDN) |
