| Part Number | AL2002A |
| Mark | Other |
| Gréisst | 2.9 |
| Applikatioun | |
| Opléisung | 20×2 |
| Zesummesetzung | OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | CPU |
| Panel Mark | Amson |
| Panel Modell | AL2002A |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 2.9 inch |
| Display Format | 20 characters × 2 lines |
| weisen Schrëften | 5×7 dots + cursor |
| Charakter Gréisst | 3.22×5.57 mm |
| Charakter Terrain | 3.70×5.95 mm |
| aktiv Beräich | 73.52×11.52 mm |
| bezel Beräich | 75.32×13.52 mm |
| skizzéieren | 116×37×9.7 mm |
| Hellegkeet | |
| Kontrast Verhältnis | |
| weisen Faarwen | Mono(White) |
| Chauffeur ic | Built-in KS0066 |
| Signal Interface | 8-bit parallel, 16 pins |
| Input Volt | 3.3V (Typ.) |
