| Part Number | LQ6NC02 |
| Mark | SHARP |
| Gréisst | 5.7 |
| Applikatioun | |
| Opléisung | 240×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 120 |
| CR | |
| Faarwen | Full color |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | SHARP |
| Panel Modell | LQ6NC02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.7 inch |
| Resolutioun | 240(RGB)×240 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 113.8×87.6 mm |
| skizzéieren | 149.4×117 mm |
| Uewerfläch | |
| Hellegkeet | 120 cd/m² (Typ.) |
| Kontrast Verhältnis | |
| weisen Faarwen | Full color |
| Äntwert Zäit | 30/50 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/30/10 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | Analog RGB + Composite Video (NTSC), 20 pins |
| Input Volt | 5.0V (Typ.) |
