| Part Number | LTP350QV-E06 |
| Mark | Samsung |
| Gréisst | 3.5 |
| Applikatioun | |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | 60 |
| CR | 80:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SAMSUNG |
| Panel Modell | LTP350QV-E06 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 53.64×71.52 mm |
| skizzéieren | 64.3×87.1×4.85 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 60 cd/m² (Typ.) |
| Kontrast Verhältnis | 80:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 40 (Typ.)(Tr+Td) |
| Vue Wénkel | 40/40/25/35 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | WLED |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| Input Volt | 3.3/5.0V (Typ.)(DVDD/AVDD) |
