LG Display LH350H01-FD01-A41 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LH350H01-FD01-A41

LH350H01-FD01-A41
LH350H01-FD01-A41 thumb
Mark
LG Display
Gréisst
3.5
Applikatioun
MPH
Opléisung
320×480
Zesummesetzung
LCM
Hellegkeet
450
CR
200:1
Faarwen
16.7M
Backlight
WLED
Interface
MIPI
In Stock
15022
Spezifikatioune

Part Number LH350H01-FD01-A41
MarkLG Display
Gréisst3.5
ApplikatiounMPH
Opléisung320×480
ZesummesetzungLCM
Hellegkeet450
CR200:1
Faarwen16.7M
GéigeliichtWLED
InterfaceMIPI
Panel MarkLG Display
Panel ModellLH350H01-FD01-A41
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst3.5 inch
Resolutioun320(RGB)×480 , HVGA
Display ModusTN, Normally White, Transflective
aktiv Beräich49.92×74.88 mm
skizzéieren55.14×82.84×2.25 mm
Uewerfläch
Hellegkeet450 cd/m² (Typ.)
Kontrast Verhältnis200:1 (Typ.)(Transmissive)
weisen Faarwen16.7M (8-bit)
Äntwert Zäit6/20 (Typ.)(Tr/Td); 40 (Typ.)(G to G)
Vue Wénkel60/60/60/57 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ6S1PWLEDWithout Driver
Signal InterfaceMIPI (2 data lanes), 20 pins
Input Volt3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LOVCC)
ApplikatiounMPH
Famill Modell
35HVE1H SII 3.5 320×480
AM-320240LATNQW-00H-F AMPIRE 3.5 320×240
COM35H3M10XTC ORTUSTECH 3.5 240×320
LH350H01-FD01 LG Display 3.5 320×480
LH350H01-FD01-A41 LG Display 3.5 320×480
LQ035Q5DG01 SHARP 3.5 320×240
LQ035Q7DH05 SHARP 3.5 240×320
LTJ035L001A TPO 3.5 640×360
NL2432HC22-23B NLT 3.5 240×320
TM035PDZ15 Tianma 3.5 320×480
