| Part Number | LH530QH1-SD01 |
| Mark | LG Display |
| Gréisst | 5.3 |
| Applikatioun | MPH |
| Opléisung | 1440×2560 |
| Zesummesetzung | Assembly |
| Hellegkeet | 500 |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LH530QH1-SD01 |
| Panel Typ | LTPS TFT-LCD , Assembly |
| Panel Gréisst | 5.3 inch |
| Resolutioun | 1440(RGB)×2560 , Quad-HD |
| aktiv Beräich | 65.88×117.12 mm |
| skizzéieren | 70.3×135.19×1.86 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193185% |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | MIPI (2 ch, 4 data lanes), 54 pins |
| Input Volt | 1.8/3.3/5.4/-5.4V (Typ.)(VDDI/VPNL/DDVDH/DDVDL) |
| Applikatioun | MPH |
