| Part Number | LH300WQ1-ED01 |
| Mark | LG Display |
| Gréisst | 3.0 |
| Applikatioun | MPH |
| Opléisung | 240×400 |
| Zesummesetzung | OLED |
| Hellegkeet | 210 |
| CR | 2000:1 |
| Faarwen | 65K/262K |
| Géigeliicht | self |
| Interface | CPU/RGB/SPI |
| Panel Mark | LG Display |
| Panel Modell | LH300WQ1-ED01 |
| Panel Typ | AM-OLED , OLED |
| Panel Gréisst | 3.0 inch |
| Resolutioun | 240(RGB)×400 , WQVGA |
| aktiv Beräich | 38.88×64.8 mm |
| skizzéieren | 44×74.6 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 210 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000 : 1 (Min.) |
| weisen Faarwen | 65K/262K , CIE193185% |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 40 pins |
| Input Volt | 2.8/2.8/3.7V (Typ.)(VDD/VCC/VBATT) |
| Applikatioun | MPH |
