| Part Number | AMS470GS16-1 |
| Mark | Samsung |
| Gréisst | 4.7 |
| Applikatioun | MPH |
| Opléisung | 720×1280 |
| Zesummesetzung | Assembly |
| Hellegkeet | 300 |
| CR | 3400:1 |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | MIPI |
| Panel Mark | SAMSUNG |
| Panel Modell | AMS470GS16-1 |
| Panel Typ | AM-OLED , Assembly |
| Panel Gréisst | 4.7 inch |
| Resolutioun | 720RG(BG)×1280 , WXGA |
| aktiv Beräich | 57.96×103.04 mm |
| skizzéieren | 66.36×131.8 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 3400 : 1 (Min.) |
| weisen Faarwen | 16.7M (8-bit), CIE1931110% |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | MIPI (4 data lanes), 44 pins |
| Input Volt | 2.5/3.1/3.8V (VDD3/VCI/VBAT) |
| Applikatioun | MPH |
| 990001086 | Innolux | 3.0 | |
| ACX399CMP-7 | SONY | 2.9 | 640×360 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS397GE66 | Samsung | 4.0 | 480×800 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| EJ030NC-02A | Innolux | 3.0 | |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LTJ035L001A | TPO | 3.5 | 640×360 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
