| Part Number | AMDM001 |
| Mark | Samsung |
| Gréisst | 2.6 |
| Applikatioun | MPH |
| Opléisung | 240×400 |
| Zesummesetzung | OLED |
| Hellegkeet | 200 |
| CR | 2000:1 |
| Faarwen | 262K |
| Géigeliicht | self |
| Interface | CPU |
| Panel Mark | SAMSUNG SDI |
| Panel Modell | AMDM001 |
| Panel Typ | AM-OLED , OLED |
| Panel Gréisst | 2.6 inch |
| Resolutioun | 240(RGB)×400 , WQVGA |
| aktiv Beräich | 33.84×56.4 mm |
| skizzéieren | 37.78×64.7×2 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000 : 1 (Min.) |
| weisen Faarwen | 262K (6-bit), CIE1931106% |
| Vue Wénkel | |
| Chauffeur ic | Built-in D53E4EA7554 |
| Signal Interface | CPU, 40 pins |
| Input Volt | 1.8/2.8V (Typ.)(VCI/VDD2) |
| Applikatioun | MPH |
