| Part Number | LH530WX1-SH02 |
| Mark | LG Display |
| Gréisst | 5.3 |
| Applikatioun | MPH |
| Opléisung | 720×1280 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 900:1 |
| Faarwen | |
| Géigeliicht | No B/L |
| Interface | |
| Panel Mark | LG Display |
| Panel Modell | LH530WX1-SH02 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 5.3 inch |
| Resolutioun | 720(RGB)×1280 , WXGA |
| Display Modus | AH3-IPS, Normally Black, Transmissive |
| aktiv Beräich | 65.45×116.35 mm |
| skizzéieren | 68.048×123.652×0.3 mm |
| Uewerfläch | |
| Glas Déift | 0.15+0.15 mm |
| transmissivitéit | 3.5% (Typ.)(with Polarizer) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | , CIE193174% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Chauffeur ic | COG Suggest HX8394-A01, NT33520, NT35521, OTM1283A, OTM1288A |
| Applikatioun | MPH |
