| Part Number | HSD060FMW1-C00 |
| Mark | HannStar |
| Gréisst | 6.0 |
| Applikatioun | MPH |
| Opléisung | 540×960 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | MIPI |
| Panel Mark | HannStar |
| Panel Modell | HSD060FMW1-C00 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 6.0 inch |
| Resolutioun | 540(RGB)×960 , qHD |
| Display Modus | IPS Pro, Normally Black, Transmissive |
| aktiv Beräich | 73.99×131.53 mm |
| skizzéieren | 76.58×139.02×0.5 mm |
| Uewerfläch | Without Polarizer |
| Glas Déift | 0.25+0.25 mm |
| transmissivitéit | 11.52% (Typ.)(without Polarizer) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Chauffeur ic | Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
| Signal Interface | MIPI (2 data lanes) |
| Applikatioun | MPH |
