| Part Number | H446TAN01.1 |
| Mark | AUO |
| Gréisst | 4.5 |
| Applikatioun | MPH |
| Opléisung | 720×1280 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | |
| Panel Mark | AUO |
| Panel Modell | H446TAN01.1 2 Compatible model |
| Panel Typ | LTPS TFT-LCD , CELL |
| Panel Gréisst | 4.5 inch |
| Resolutioun | 720(RGB)×1280 , WXGA |
| Display Modus | AHVA, Normally Black, Transmissive |
| aktiv Beräich | 55.512×98.688 mm |
| skizzéieren | 58.74×106.73 mm |
| Uewerfläch | Antireflection |
| Glas Déift | 0.20+0.20 mm |
| transmissivitéit | 4.0% (Typ.)(with Polarizer) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 20/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| Chauffeur ic | COG Built-in OTM1281A |
| Applikatioun | MPH |
| AMCB004 | Samsung | 2.4 | 240×320 |
| AMFN888 | Samsung | 3.1 | 480×800 |
| AMS397GE66 | Samsung | 4.0 | 480×800 |
| H320QN01 V2 | AUO | 3.2 | 320×480 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| LH350WS1-SD01 | LG Display | 3.5 | 640×960 |
| LMS245DC08 | Samsung | 2.4 | 480×360 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
| TX10D121VM0AAA | JDI | 4.0 | 480×800 |
