| Part Number | TFD60W12 |
| Mark | TOSHIBA |
| Gréisst | 6.0 |
| Applikatioun | IA |
| Opléisung | 320×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 80:1 |
| Faarwen | Full color |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | TOSHIBA |
| Panel Modell | TFD60W12 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 6.0 inch |
| Resolutioun | 320(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 121.92×89.154 mm |
| skizzéieren | 144×109.4 mm |
| Uewerfläch | |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 80:1 (Typ.) |
| weisen Faarwen | Full color |
| Äntwert Zäit | 70/40 (Max.)(Tr/Td) |
| Vue Wénkel | 45/45/45/15 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 24 pins |
| Input Volt | 5.0/13.0/23.0/-5.0V (Typ.)(VDD/VBB/VGG/VEE) |
| Applikatioun | IA |
