| Part Number | LQ092Y3DG01 |
| Mark | SHARP |
| Gréisst | 9.2 |
| Applikatioun | |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 380 |
| CR | 250:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ092Y3DG01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 9.2 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 200.4×120.2 mm |
| skizzéieren | 226.6×143.9 mm |
| Uewerfläch | |
| Hellegkeet | 380 cd/m² (Typ.) |
| Kontrast Verhältnis | 250:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 30/50 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/55/65 (Typ.)(CR≥5)(L/R/U/D) |
| Lampe Typ | 1 pcsCCFL |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 32 pins |
| Input Volt | 5.0V (Typ.)(VCC) |
