| Part Number | LS024Q8DD92 |
| Mark | SHARP |
| Gréisst | 2.4 |
| Applikatioun | |
| Opléisung | 240×320 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 100:1 |
| Faarwen | 65K/262K |
| Géigeliicht | No B/L |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LS024Q8DD92 |
| Panel Typ | CG-Silicon , CELL |
| Panel Gréisst | 2.4 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transflective |
| aktiv Beräich | 36.72×48.96 mm |
| skizzéieren | 41.2×58 mm |
| Uewerfläch | Hard coating (3H) |
| Glas Déift | 0.50+0.50 mm |
| Kontrast Verhältnis | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| weisen Faarwen | 65K/262K |
| Äntwert Zäit | 13/35 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| Chauffeur ic | Built-in uPD161831 |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| Input Volt | 3.0/3.0V (Typ.)(VCC/VDC) |
