| Part Number | TP241MC01G |
| Mark | Neoview Kolon |
| Gréisst | 2.4 |
| Applikatioun | MPH |
| Opléisung | 240×320 |
| Zesummesetzung | OLED |
| Hellegkeet | 140 |
| CR | |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | CPU/SPI |
| Panel Mark | Neoview Kolon |
| Panel Modell | TP241MC01G |
| Panel Typ | TOLED , OLED |
| Panel Gréisst | 2.4 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| aktiv Beräich | 36.72×48.96 mm |
| skizzéieren | 42.92×59.46×1.5 mm |
| Uewerfläch | |
| Hellegkeet | 140 cd/m² (Typ.) |
| Kontrast Verhältnis | |
| weisen Faarwen | 16.7M (8-bit) |
| Vue Wénkel | |
| Chauffeur ic | Built-in DA8620 |
| Signal Interface | 8-bit 8080 parallel, SPI, 39 pins |
| Input Volt | 18.0V (Typ.) |
| rohs: | |
| Applikatioun | MPH |
| BTL455496-W613L | BOE | 4.5 | 540×960 |
| BV045WVM-N00 | BOE | 4.5 | 480×800 |
| CLAN050LE61 1XE | CPT | 5.0 | 540×960 |
| DLC0320DUG | Other | 3.2 | 240×320 |
| DX12D100VM0EAA | JDI | 4.7 | 720×1280 |
| H347QN02 V0 | AUO | 3.5 | 320×480 |
| H430VL02 V4 | AUO | 4.3 | 480×800 |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| LS050T1SX12(K) | SHARP | 5.0 | 1080×1920 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
