| Part Number | LQ035Q7DB04 |
| Mark | SHARP |
| Gréisst | 3.5 |
| Applikatioun | |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | 50 |
| CR | 70:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ035Q7DB04 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transflective |
| aktiv Beräich | 53.64×71.52 mm |
| skizzéieren | 65×85×4.8 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 50 cd/m² (Typ.) |
| Kontrast Verhältnis | 70:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 60/100 (Typ.)(Tr/Td) |
| Vue Wénkel | 40/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 50 pins |
| Input Volt | 5.0/3.3/15.0/-10.0V (Typ.)(VSGA/VSHD/VDD/VEE) |
