| Part Number | HV089WU1-1E0 |
| Mark | HYDIS |
| Gréisst | 8.9 |
| Applikatioun | PAD |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | HYDIS |
| Panel Modell | HV089WU1-1E0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 8.9 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | HFFS, Normally Black, Transmissive |
| aktiv Beräich | 191.52×119.7 mm |
| skizzéieren | 203.5×135.9×5 mm |
| Uewerfläch | Antireflection |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 7S5PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 45 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
