| Part Number | AL1602B |
| Mark | Other |
| Gréisst | 2.3 |
| Applikatioun | |
| Opléisung | 16×2 |
| Zesummesetzung | OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | CPU |
| Panel Mark | Amson |
| Panel Modell | AL1602B |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 2.3 inch |
| Display Format | 16 characters × 2 lines |
| weisen Schrëften | 5×7 dots + cursor |
| Charakter Gréisst | 2.97×5.57 mm |
| Charakter Terrain | 3.55×5.95 mm |
| aktiv Beräich | 56.22×11.52 mm |
| bezel Beräich | 58.22×13.25 mm |
| skizzéieren | 80×36×9.7 mm |
| Hellegkeet | |
| Kontrast Verhältnis | |
| weisen Faarwen | Mono(White) |
| Chauffeur ic | Built-in KS0066 |
| Signal Interface | 8-bit parallel, 16 pins |
| Input Volt | 3.3V (Typ.) |
