| Part Number | LQ056A3AG01 |
| Mark | SHARP |
| Gréisst | 5.6 |
| Applikatioun | |
| Opléisung | 320×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 60:1 |
| Faarwen | Full color |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | SHARP |
| Panel Modell | LQ056A3AG01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.6 inch |
| Resolutioun | 320(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 114.2×83.5 mm |
| skizzéieren | 140×102.7 mm |
| Uewerfläch | |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 60:1 (Min.) |
| weisen Faarwen | Full color |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| Lampe Typ | 1 pcsCCFLEmbedded (Inverter) |
| Signal Interface | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| Input Volt | 12.0V (Typ.) |
