| Part Number | TM056KDH02 |
| Mark | Tianma |
| Gréisst | 5.6 |
| Applikatioun | VDP |
| Opléisung | 320×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 330 |
| CR | 300:1 |
| Faarwen | Full color |
| Géigeliicht | WLED |
| Interface | Analog |
| Panel Mark | TIANMA |
| Panel Modell | TM056KDH02 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.6 inch |
| Resolutioun | 320(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 113.28×84.708 mm |
| skizzéieren | 126.5×100 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 330 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | Full color , CIE193150% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 2S7PWLEDWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 26 pins |
| Input Volt | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| Applikatioun | VDP |
