| Part Number | TD036THEA3 |
| Mark | TPO |
| Gréisst | 3.6 |
| Applikatioun | |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 400:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Serial RGB |
| Panel Mark | Toppoly |
| Panel Modell | TD036THEA3 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 3.6 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 72.96×54.72 mm |
| skizzéieren | 80.2×66.3 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 13/22 (Typ.)(Tr/Td) |
| Vue Wénkel | 50/20/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 3S2PWLED |
| Signal Interface | Serial RGB (8-bit) + SPI, CCIR601, 40 pins |
| Input Volt | 3.0V (Typ.)(VCC) |
