| Part Number | M280DGJ-L30 |
| Mark | Innolux |
| Gréisst | 28.0 |
| Applikatioun | DMPC |
| Opléisung | 3840×2160 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1000:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | V-by-One |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | M280DGJ-L30 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 28.0 inch |
| Resolutioun | 3840(RGB)×2160 , UHD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 620.93×341.28 mm |
| skizzéieren | 648.9×369.3×20.85 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 1.07B (10-bit), CIE193172% |
| Äntwert Zäit | 1.5/3.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 stringsWLEDWithout Driver |
| Signal Interface | V-by-One 8 lane, 51 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
