| Part Number | TX38D14VC0CAA |
| Mark | KOE |
| Gréisst | 15.0 |
| Applikatioun | DMPC |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 300:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | HITACHI |
| Panel Modell | TX38D14VC0CAA |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 304.128×228.096 mm |
| skizzéieren | 350×265 mm |
| Uewerfläch | |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 25/25 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
