| Part Number | LTM240CL04 |
| Mark | Samsung |
| Gréisst | 24.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTM240CL04 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 24.0 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | PLS, Normally Black, Transmissive |
| aktiv Beräich | 518.4×324 mm |
| skizzéieren | 546.4×350×11.2 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 15 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 13S3PWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| LM240WU7-SLA3 | LG Display | 24.0 | 1920×1200 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| LTM240CL04 | Samsung | 24.0 | 1920×1200 |
| LTM240CS02 | Samsung | 24.0 | 1920×1200 |
| LTM240CS09 | Samsung | 24.0 | 1920×1200 |
| LTM240CT01 | Samsung | 24.0 | 1920×1200 |
| LTM240CT03 | Samsung | 24.0 | 1920×1200 |
| LTM240CT04 | Samsung | 24.0 | 1920×1200 |
| LTM240CT06 | Samsung | 24.0 | 1920×1200 |
| M240HTN01.2 | AUO | 24.0 | 1920×1080 |
| FLC38XGC6V-06 | Fujitsu | 15.0 | 1024×768 |
| HT170E01-300 | BOE | 17.0 | 1280×1024 |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| LM156WH1-TLE1 | LG Display | 15.6 | 1366×768 |
| LTM236FL01 | Samsung | 23.6 | 3840×2160 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| M215HTN01.1 | AUO | 21.5 | 1920×1080 |
| M240UP01 V0 | AUO | 24.0 | 1920×1200 |
| MT190AW01 V.7 | Innolux | 19.0 | 1440×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
