| Part Number | LM240WU6-SDA1 |
| Mark | LG Display |
| Gréisst | 24.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 320 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | LG Display |
| Panel Modell | LM240WU6-SDA1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 24.0 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | S-IPS, Normally Black, Transmissive |
| aktiv Beräich | 518.4×324 mm |
| skizzéieren | 546.4×361.6×18.8 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H), Antireflection |
| Hellegkeet | 320 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193176% |
| Äntwert Zäit | 6.5/7.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 50 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
