| Part Number | LQ104X2LX05B |
| Mark | SHARP |
| Gréisst | 10.4 |
| Applikatioun | PAD |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | |
| Faarwen | 262K |
| Géigeliicht | |
| Interface | LVDS |
| Panel Mark | SHARP |
| Panel Modell | LQ104X2LX05B |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.4 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | Reflective |
| aktiv Beräich | 212×159 mm |
| Uewerfläch | |
| Hellegkeet | |
| Kontrast Verhältnis | |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | |
| Vue Wénkel | |
| Frequenz | 60Hz |
| Lampe Typ | |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
