| Part Number | LD083WU1-SPA3 |
| Mark | LG Display |
| Gréisst | 8.3 |
| Applikatioun | PAD |
| Opléisung | 1200×1920 |
| Zesummesetzung | Assembly |
| Hellegkeet | 370 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | LG Display |
| Panel Modell | LD083WU1-SPA3 |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Panel Gréisst | 8.3 inch |
| Resolutioun | 1200(RGB)×1920 , WUXGA |
| aktiv Beräich | 111.31×178.1 mm |
| skizzéieren | 128×220.3 mm |
| Uewerfläch | Anti Fingerprint, Hard coating (8H) |
| Hellegkeet | 370 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193160% |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | eDP (2 Lanes), 34 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| LD083WU1-SPA3 | LG Display | 8.3 | 1200×1920 |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EVT04.0 | AUO | 10.1 | 1280×800 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| LP079X01-SMAV | LG Display | 7.9 | 768×1024 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
