| Part Number | NL6448BC33-50 |
| Mark | NLT |
| Gréisst | 10.4 |
| Applikatioun | IA |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 100:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | NEC |
| Panel Modell | NL6448BC33-50 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.4 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transflective |
| aktiv Beräich | 211.2×158.4 mm |
| skizzéieren | 243×185.1×11.5 mm |
| Uewerfläch | Clear, Hard coating (2H), Antireflection |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 5/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 75/55/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | CMOS (1 ch, 6-bit), 31 pins |
| Input Volt | 3.3/5.0V (Typ.)(VCC) |
| Applikatioun | IA |
