| Part Number | LP079X01-SMA1 |
| Mark | LG Display |
| Gréisst | 7.9 |
| Applikatioun | PAD |
| Opléisung | 768×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 425 |
| CR | 900:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LP079X01-SMA1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.9 inch |
| Resolutioun | 768(RGB)×1024 , XGA |
| Display Modus | AH-IPS, Normally Black, Transmissive |
| aktiv Beräich | 119.808×159.744 mm |
| skizzéieren | 129×171.07×4.81 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating |
| Hellegkeet | 425 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 17 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6 stringsWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 32 pins |
| Input Volt | 3.6V (Typ.) |
| Applikatioun | PAD |
