| Part Number | LTL070NL01-002 |
| Mark | Samsung |
| Gréisst | 7.0 |
| Applikatioun | PAD |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 800:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTL070NL01-002 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 1024(RGB)×600 , WSVGA |
| Display Modus | PLS, Normally Black, Transmissive |
| aktiv Beräich | 153.6×90 mm |
| skizzéieren | 164.05×99.96×4.37 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC), CIE193150% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S4PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 31 pins |
| Input Volt | 3.7V (Typ.) |
| Applikatioun | PAD |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| LP097X02-SLA3 | LG Display | 9.7 | 1024×768 |
| LQ104X2LX05A | SHARP | 10.4 | 1024×768 |
| LTN070NL01-801 | Samsung | 7.0 | 1024×600 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
