| Part Number | P101DEA-AZ0 |
| Mark | Innolux |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 800×1280 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 strings WLED , 15K hours , No Driver |
| Interface | MIPI |
| Fabrikant beschwéiert | Innolux |
| Modell Numm | P101DEA-AZ0 |
| Écran Gréisst | 10.1 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×1280 (WXGA) 150PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 135.36 × 216.576 (H×V) |
| Kontur (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Glare (Haze 0%), Hard coating |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| Äntwert | 35 (Max.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AAS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 60% NTSC |
| mass | 175g (Max.) |
| benotzt fir | Pad & Tablet |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | MIPI (4 data lanes) , Connector 40 pins |
| Spannungsversuergung | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. Bewäertungen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
