MT185WHM-N10


Mark
BOE
Gréisst
18.5
Applikatioun
DMPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
200
CR
600:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
5761
Spezifikatioune

Part Number MT185WHM-N10
MarkBOE
Gréisst18.5
ApplikatiounDMPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet200
CR600:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkBOE
Panel ModellMT185WHM-N10
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst18.5 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich409.8×230.4 mm
skizzéieren430.4×254.6×11.4 mm
UewerflächAntiglare (Haze 25%), Hard coating (3H)
Hellegkeet200 cd/m² (Typ.)
Kontrast Verhältnis600:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit1.5/3.5 (Typ.)(Tr/Td)
Vue Wénkel45/45/25/40 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
