| Part Number | LM201U04-SL03 |
| Mark | LG Display |
| Gréisst | 20.1 |
| Applikatioun | DMPC |
| Opléisung | 1600×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG.Philips LCD |
| Panel Modell | LM201U04-SL03 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 20.1 inch |
| Resolutioun | 1600(RGB)×1200 , UXGA |
| Display Modus | S-IPS, Normally Black, Transmissive |
| aktiv Beräich | 408×306 mm |
| skizzéieren | 432×331.5×25.5 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 7/9 (Typ.)(Tr/Td); 12 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 20.0V (Typ.) |
| Applikatioun | DMPC |
