| Part Number | M220Z1-P03 |
| Mark | Innolux |
| Gréisst | 22.0 |
| Applikatioun | DMPC |
| Opléisung | 1680×1050 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Panel Mark | CMO |
| Panel Modell | M220Z1-P03 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 22.0 inch |
| Resolutioun | 1680(RGB)×1050 , WSXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 473.76×296.1 mm |
| skizzéieren | 485.26×307.6 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Glas Déift | 0.70+0.70 mm |
| transmissivitéit | 5.8% (Typ.)(with Polarizer) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 1.3/3.7 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
