| Part Number | M280HKJ-L30 |
| Mark | Innolux |
| Gréisst | 28.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | M280HKJ-L30 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 28.0 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | MVA, Normally Black, Transmissive |
| aktiv Beräich | 620.928×341.28 mm |
| skizzéieren | 649.3×369.6×15.3 mm |
| Uewerfläch | Antiglare (Haze 3.4%), Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 3000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 6.5 (Typ.)(G to G) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 stringsWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
