| Part Number | LM260WU1-SLB1 |
| Mark | LG Display |
| Gréisst | 25.5 |
| Applikatioun | DMPC |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG.Philips LCD |
| Panel Modell | LM260WU1-SLB1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 25.5 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | S-IPS, Normally Black, Transmissive |
| aktiv Beräich | 550.08×343.8 mm |
| skizzéieren | 582×375.6 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193192% |
| Äntwert Zäit | 5.5/6.5 (Typ.)(Tr/Td); 5 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 16 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
