| Part Number | LTM190BT07 |
| Mark | Samsung |
| Gréisst | 19.0 |
| Applikatioun | DMPC |
| Opléisung | 1440×900 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTM190BT07 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 19.0 inch |
| Resolutioun | 1440(RGB)×900 , WXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 408.24×255.15 mm |
| skizzéieren | 428×278×10.3 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 5 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S3PWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| LTM190ET01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L05 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L31 | Samsung | 19.0 | 1280×1024 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM190M2-L31(Glare) | Samsung | 19.0 | 1440×900 |
| LM230WF5-TRA1 | LG Display | 23.0 | 1920×1080 |
| LM240WU2-SLB1 | LG Display | 24.0 | 1920×1200 |
| LM240WU7-SLA1 | LG Display | 24.0 | 1920×1200 |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M195RTN01.0 | AUO | 19.5 | 1600×900 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
| NL12876AC39-01 | NLT | 23.0 | 1280×768 |
